Hailea HAP-200 Air Pump – High-Performance Professional Aerator

The Hailea HAP-200 Linear Air Pump is a top-of-the-line diaphragm compressor engineered for large ponds, aquaculture tanks, and hydroponics systems. Delivering a massive 200 litres per minute (12,000 L/h) with steady pressure up to 0.054 MPa, the HAP-200 ensures optimal oxygenation even under high backpressure and deep-water conditions.

With its aluminium alloy housing for heat dissipation, advanced sound-damping system, and energy-efficient 160W motor, the HAP-200 is built for continuous 24/7 operation, offering reliability, quiet performance, and a long service life.

Key Features of Hailea HAP-200 Air Pump

✅ High Airflow Output – Pumps up to 200 L/min (12,000 L/h) for large-scale aeration.
✅ Energy Efficient – Consumes only 160W, minimizing operating costs.
✅ Quiet Operation – Advanced muffler system keeps noise at ≤45 dB.
✅ Durable Build – Strong aluminum alloy casing ensures efficient cooling.
✅ Steady Pressure – Diaphragms made from special synthetic rubber for consistent output.
✅ Outdoor Safe – Protected against water ingress, ideal for pondside installation.
✅ Versatile Applications – Perfect for koi ponds, aquaculture tanks, fish farms, hydroponics, and quarantine facilities.

Specifications

• Brand: Hailea
• Model: HAP-200
• Air Output: 200 L/min (12,000 L/h)
• Power Consumption: 160W
• Voltage: 220–240V / 50Hz
• Max Pressure: 0.054 MPa
• Common Pressure: 0.02 MPa
• Noise Level: ≤45 dB
• Weight: 13.6–15 kg
• Dimensions: 238 × 196 × 177 mm
• Outlet Size: 20 mm brass nozzle with 26-way manifold
• Casing Material: Aluminium alloy (Gray finish)

Product Description

The Hailea HAP-200 Hi-Blow Air Pump is built for demanding applications that require high airflow and reliable oxygenation. Its professional-grade diaphragm compressor provides the power to operate multiple air stones, deep-water diffusers, and large aquaculture systems simultaneously.

The pump’s multi-stage muffler system ensures whisper-quiet performance, while the high-efficiency diaphragms maintain consistent airflow for years. The rugged aluminium alloy case aids in quick heat dissipation, ensuring long-term durability even under continuous 24/7 use.

Applications include:

• Large koi ponds and ornamental water gardens.
• Aquaculture farms and fish hatcheries.
• Hydroponic and aquaponic systems.
• Breeding, sales, and quarantine tanks.
• Deep-water aeration with multiple diffusers.

Installation & Usage

• Always place the pump above the waterline to prevent backflow.
• Use the included 26-way manifold to distribute air across multiple outlets.
• Connect with air stones, diffusers, or filters for optimal oxygenation.
• Suitable for indoor or outdoor installation (with protection from rain).

Why Choose the Hailea HAP-200?

Compared to smaller models like the HAP-120 or HAP-100, the HAP-200 delivers nearly double the airflow and higher pressure capacity, making it ideal for professional and large-scale pond or aquaculture projects. It combines raw power, low noise, and energy efficiency, ensuring exceptional performance and reliability.

FAQs – Hailea HAP-200 Air Pump

Q1: How much airflow does the HAP-200 provide?
👉 It delivers up to 200 L/min (12,000 L/h).

Q2: How much power does it consume?
👉 The HAP-200 consumes 160W, making it efficient for its size.

Q3: Is it noisy?
👉 No, it operates at just ≤45 dB, extremely quiet for its power class.

Q4: Can it be used outdoors?
👉 Yes, it is protected against water ingress, but it should be shielded from direct rain.

Q5: What makes it different from the HAP-120?
👉 The HAP-200 offers higher airflow and stronger pressure handling, making it suitable for larger ponds and commercial aquaculture setups.
